Soyuz-5
RKK Energiya · Russia
Soyuz-5, also named Irtysh is a planned Russian rocket that is being developed by JSC SRC Progress, formerly within "Project Feniks." It will replace the capability of Zenit-2 and Proton Medium. It will initially be a two-stage rocket, but Soyuz 5 can be enhanced with an optional Blok DM-03 upper stage for geostationary missions. The rocket is loosely based on the Zenit launch vehicle with a RD-171MV engine on the 1st stage, enlarged to 4.1 m in diameter, while the 2nd stage is powered by 2 RD-0124MS engines derived from engines used on the 3rd stage of the Soyuz-2.1b. The Soyuz-5 can lift 17 tonnes to a Low Earth orbit.
- Costruttore
- RKK Energiya
- Primo volo
- 30 aprile 2026
- Lanci
- 1
- Riusciti
- 1
- Falliti
- 0
- Altezza
- 65,258 m
- Diametro
- 4,1 m
- Massa al decollo
- 525 t
- Carico in orbita bassa
- 17.000 kg
- Carico in orbita di trasferimento geostazionaria
- 5.000 kg
- Riutilizzabile
- no
